Detailed parameters

Connecting wire: PVC, temperature resistance range: -5 to 85 °C

Silicone, temperature resistance range: -50 to 180°C

Polytetrafluoroethylene, with a temperature resistance range of -50 to 260°C

Glass fiber, with a temperature resistance range of -50 to 350°C

Protective sleeve: Stainless steel 304 or 316.

Outer diameter: 4mm, 5mm, 6mm, 8mm

Temperature sensing element: Pt100, Pt500, Pt1000, in accordance with IEC 751

Accuracy grade: B level: △t = ±(0.30 + 0.0051 × I) °C

Grade A: △t = ±(0.15 + 0.002ltI) °C

Response time: When the outer diameter is 4mm, t0.9 is approximately 4 seconds, and in water it is 0.2 m/sec.
