Connecting wires: PVC, temperature resistance range: -5 to 85 °C

Silicone, temperature resistance range: -50 to 180 °C

Polytetrafluoroethylene, temperature resistance range: -50 to 260 °C

Glass fiber, temperature resistance range: -50 to 350 °C

Protective sleeves: Stainless steel 304 or 316,

Outer diameter: 4mm, 5mm, 6mm, 8mm

Temperature sensing elements: Pt100, Pt500, Pt1000, in accordance with IEC 751

Accuracy grade: B grade: △t = ±(0.30 + 0.0051ltI) °C

A grade: △t = ±(0.15 + 0.002ltI) °C

Response time: When the outer diameter is 4mm, t0.9 is approximately 4 seconds, and in water at 0.2 m/sec
